How do I track my order?

After purchase, you can track your order by providing the order number and e-mail received during confirmation, or through the provided carrier tracking number when your order has been shipped.

Track Your Order

What does shipping cost?

We use FedEx to ship globally. Shipping is calculated automatically during checkout. For shipments outside the USA, please contact us to get the name of a local reseller or for details and charges on shipping from the USA. For more information follow the link below.

https://store.ohmnilabs.com/pages/shipping-and-warranty-details/

How can I become a reseller?

OhmniLabs works with approved technology resellers across the globe. For more information about becoming a reseller, please complete our contact form.

What are the full specs for the Ohmni® Robot?

Dimensions
Height 56 inches (142.2 cm)
Base Footprint 13.9 x 17.2 inches (35.3 x 43.7 cm)
Charging Dock
Height 2.1 inches
Base 5.5 x 4.7 inches (14.0 x 11.9 cm)
Display
Resolution 1280×800
Touch points 5 simultaneous
Panel type IPS
CPU
Processor Intel Atom X5 Z8350 1.92 GHz
Number of cores 4 Cores
Memory 2GB DDR3L
Storage 16 GB eMMC
USB ports 4 USB 2.0 A (full size)
1 USB 3.0 Micro B OTG
Video ports 1 HDMI
Speaker
Speaker type 50mm Full Range Neodyne
Speaker range 250 HZ – 14kHz
Speaker volume 48dB volume range
Microphone
Mic type 6mm Omnidirectional
Microphone range 100Hz – 10kHz
Folding hinge
Power button Illuminated, software on-off
Release Interlocking pull-to-release
Neck servo
Torque 12kgf-cm
Rotation speed 60 deg/sec
Encoder type 10-bit absolute
Protocol Serial multidrop, packet based
WiFi
Standards IEEE802.11 ac/a/b/g/n
Encryption WPA/WPA-PSK,WPA2/WPA2-PSK. WPA-Enterprise (802.11x)
Battery system
Charge rate 20W
Cell protection Undervoltage, Overvoltage, Short circuit, Current limit, Cell failure
Cell balancing Yes
Battery chemistry LiFePO4
Battery capacity 95Wh
Runtime 4-5h at full load
Input 100-240V AC, 50/60 Hz
Front camera (Supercam)
Sensor res 2MP
Maximum res 4208×3120
Streaming res 1280×960 (With real-time 3x superzoom to native 4K resolution)
Chroma RGB Bayer
Pixel size 3.0 micron
Sensor size 5865 x 3276 um
Nav camera
Sensor res 2MP
Maximum res 1920×1080
Streaming res 320×240
Chroma RGB Bayer
Pixel size 3.0 micron
Sensor size 5865 x 3276 um
Drive system
Motor power 2x 30W
Motor type Three phase brushless
Maximum speed 2 mph
Carrying capacity 20 lbs
E-brake Yes, automatically engaged
Stall detection Yes, automatic
Electronic torque limiting Yes
Encoder 14-bit/revolution absolute
Transmission 11:30 timing belt reduction
Protocol Serial multidrop, packet based
